Automatic Liquid Surface Tensiometer Interface Tensiometer Liquid Surface Tension Measuring Instrument 1000mN/m Interface Tension Meter with 0.1mN/m Accuracy, AC110V 0-1000mN/m Test Range

Product Parameters Voltage: AC110V Power: 100W Test Range: 0-1000mN/m Precision: 0.1mN/m Measure Time: Normally within 60 seconds Test Method: Du Nouy Ring Method & Wilhelmy Plate Method Ring size:Pt wire radius is 0.185mm, ring radius is 9.55mm, ring circumference is 60mm. Display Method: 4.3-inch touch screen Data Method: Support data storage/view/print (Printer is optional) Machine size: 8.3*11.0*14.2" (21×28×36cm) Package size: 18.9*13.4*21.3" (48×34×54cm) Net weight/Gross weight: 20.5lbs(9.3kg)/25.1lbs(11.4kg) One package includes Liquid Surface Tension Meter *1 Accessory Kit *1 Please note: The standard configuration is the ring, and the plate needs to be purchased The plate/ring test method needs to be specified when ordering

• Clear Transparent Testing Process: The testing device is equipped with two transparent doors, which can be closed after putting the sample and keep the workspace clean, besides, the sample table inside the meter can be automatically lifted and lowered, suitable for different containers and sample quantities
• Real-time Data Display: The liquid surface tension tester adopts automatic testing mode to minimize human error, at the same time, there is a 4.3-inch LCD touch screen installed at the bottom of the machine, which can display the test data in real time and easily complete the required operations
• Precise Testing Result: There is a level on the top to ensure that the meter is in a horizontal state and ensure the results' accuracy, the measuring meter is also equipped with a high-precision sensor, so that the equippment can always work in a stable state, please note that before testing, you need to turn the level adjustment knob at the bottom until the bubble is in the middle of the level
• Data Storage Function: The machine has a password management function to effectively protect test data traceability, prevent data from being modified or accidentally deleted, it can also save multiple sets of data, support external printers
• Applicable to Various Places: With the feature of automatic way, high precision and safe operation, the liquid surface tensiometer is widely used to test different liquid types, such as transformer oil (ASTM D-971), wetting agents, cleaners, emulsifiers and cooling lubricants, suitable for scientific research, industry, food and education to meet diversified measurement needs
